We at Intranox are specialized in the manufacture of agitator tanks.
We offer a wide range agitator tanks with different storage capacities ranging from 500 gallons to 500,000 gallons and every type of agitator (propellers, blades, anchors, turbines, cowles, magnetic) that you can imagine. Our facilities are ready to design, manufacture and install in your factory whatever stainless Steel mixer tank that you need.
Keep reading and discover all that Intranox can do for your factory:
Installed Agitator Tanks Projects
What is an Agitator Tank
A stainless steel agitator tank is a vessel specially designed for mixing fluids at different viscosities, densities and temperatures.
For this purpose, all our tanks are equipped with a motor that drives the agitation system for mixing the liquids. This motor is set to meet the different power required according to the dimensions of the tank, the products to be mixed and the type of mixture desired (mixture in suspension, emulsion...).
Therefore, they are very useful equipment to achieve homogeneity in the mixing of substances and raw materials, both in the food industry and for the demanding needs of the pharmaceutical and chemical industry.
Features and Technical Specifications
Our stainless steel agitator tanks can incorporate different technical details that can also be configured:
- AISI 304 or 316 grade stainless steel construction.
- Capacities from 1000 liters to 500.000 liters.
- Customized diameters
- Wall thickness: 4 mm, 6 mm, 7.5 mm, 8 mm, 10 mm and etc.
- Double wall insulation in order to keep the water hot or cold.
- Different types of agitation systems according to fluid viscosity: anchor, propellers, blades or turbine.
- Accessories on request: product inlet and outlet, water, bolts, sealing tapes, traction rod, connection of different types of flanges, manholes, aeration or inerting inlets, ladders, base channel (C channel), etc.
- Specific designs to increase stability and rigidity. 3 or 4 support legs
- Manhole at the top
- Several bottom options: double flat bottom with total emptying, flat bottom with inclination, klopper bottom, conical bottom with different degrees...
- Incorporation of CIP cleaning balls to automate the washing installation.
- Outlet valves at the bottom, level meter Supply, assembly and control of all types of levels.
- Designed with inner or outer jacket or coil for cooling or heating.
- Compliance with ATEX regulations if required.
Each tank we manufacture is unique so you can configure the dimensions, accessories and necessary elements to fit your specific needs.
Main Benefits of this Type of Tanks
The stainless steel tanks with agitator that we manufacture at Intranox have innumerable advantages for our customers. However, we can always highlight these main advantages that will make your day to day operations more efficient
100% custom-made Stirred Tanks
That's right, all our tanks are built under the guidelines of our customers. We have a team of engineers and modern technologies ready to design and manufacture the stainless steel tank you need.
Hygienic, Clean and Low Maintenance Tanks
If you are looking for the most operative method for your production process regarding the mixing of substances, we can assure you that our tanks guarantee the best performance by reducing cleaning and maintenance tasks to a minimum. This will allow you to achieve substantial improvements in production times by significantly reducing the time spent to prepare the tank between mixing and mixing.
High Quality, Resistance and Durability
We comply with all national and international regulations for the manufacture of your tanks or reservoirs. This allows us to guarantee the maximum durability and resistance of the equipment we deliver to you. In addition, they are experts in sealing and welding in stainless steel delivering impeccable work free of cracks or roughness that favor corrosion. All our tanks are guaranteed on the structural components of the tank. And of course they can achieve long life cycles with proper use and maintenance.
Turnkey Project
All our projects can be ordered under the "turnkey" format, which means that we take care of everything. This way we save you problems and worries so that you can focus on what really matters: your business.
Why Buy Intranox's Tanks with agitator?
At intranox we rely on an accumulated tradition of 30 years manufacturing this type of tailor-made tanks. Therefore, we are backed by a long experience supported by a great team of professionals: from engineers specialized in the use of the most modern design techniques to expert assemblers, through a highly professionalized workshop team in clean welding and stainless steel works.
Not only that, but we also have facilities of more than 30,000 square meters that allow us to undertake projects of large dimensions and different sizes. Regardless of your requirements, at Intranox we are sure we can support you throughout the whole process.
We are used working side by side with your team and your engineers or we can make your life easier and take care of the project's integral management: Turnkey.
For all these reasons and many others you can be sure that you are in good hands.
If you need more information about our tanks with agitators, please contact our team through the web form or this phone number: +34 941 27 02 48
We will be pleased to help you.
